Plain weave wire mesh is widely adopted in industries requiring particle separation, liquid filtration and safety guarding. Its simple one-over-one-under plain weaving creates uniform square holes and flat mesh surface. Architects and equipment designers often match this woven mesh with Decorative Perforated Panels for combined ventilation and facade solutions. Structural design references for metal screen panels can be found in technical documents published by ASCE Engineering.
Common application scenarios for plain woven wire mesh include industrial powder sieving, liquid filtration, mechanical equipment protective guards, insect screens, acoustic panels, battery separator mesh and chemical processing filter screens. The regular square opening delivers consistent particle separation performance and easy cutting & bending fabrication. For complete industrial filtration system design, many specifiers pair this mesh with Anti-Slip Perforated Panels to meet multi-functional safety requirements. Tolerance standards for woven wire cloth are defined by ISO Standards.
Plain Weave Wire Mesh Standard Parameters
Custom cutting, bending and cut-to-size sheet service are available.
| Mesh Count | Aperture (mm) | Wire Diameter (mm) |
|---|
| 4 mesh | 1.20 | 0.60 |
| 6 mesh | 0.80 | 0.50 |
| 8 mesh | 0.60 | 0.45 |
| 10 mesh | 0.48 | 0.40 |
| 20 mesh | 0.28 | 0.25 |
| 30 mesh | 0.22 | 0.20 |
| 40 mesh | 0.16 | 0.15 |
| 60 mesh | 0.12 | 0.12 |
| 80 mesh | 0.09 | 0.10 |
| 100 mesh | 0.075 | 0.08 |
| 120 mesh | 0.063 | 0.07 |
| 200 mesh | 0.045 | 0.05 |
Standard roll width 1000mm 1220mm 1500mm 2000mm Standard roll length 30m 50m 100m
Cut sheet sizes 1000×2000mm 1220×2440mm 1250×2500mm 1500×3000mm
Material options SS304 304L 316 316L stainless steel galvanized mild steel aluminum wire brass wire
Pattern options Plain weave square opening
Surface treatment Hot dipped galvanized electro-polished pickling passivation
Readers can learn metal wire weaving techniques from technical guides released by Metal Construction Association.
When selecting plain weave wire mesh mesh count aperture and wire diameter must match filtration or sieving requirements. Higher mesh count means finer aperture for small particle filtering thicker wire gives stronger tensile strength. The plain weave layout ensures uniform opening distribution and stable mesh geometry. Research on filtration performance of woven metal mesh can be explored in research papers published by Acoustical Society of America. Long-term galvanized coating corrosion performance data is documented in Corrosion Science Journal.
Our plain weave wire mesh complies with global woven wire cloth specifications. Stainless steel mesh follows ASTM E2016 galvanized mesh meets ASTM A653 weaving tolerance complies with ISO 9044. Industrial filter application references are introduced on Architectural Digest. All finished mesh rolls and cut sheets pass dimensional inspection before shipment. Coating inspection specifications are defined by Society for Protective Coatings.
A food processing manufacturer previously used unstable low-quality woven mesh for powder sieving. Uneven holes caused inconsistent grading and frequent mesh tearing during vibration. They switched to our SS304 plain weave wire mesh of 60 mesh. Uniform square openings guaranteed stable particle classification and 304 stainless steel resisted moisture and food corrosion. Welding and assembly guidance for metal mesh assemblies can be found at American Welding Society. Material tensile load testing methodology can be checked on National Institute of Standards and Technology.
Plain weave wire mesh delivers reliable sieving filtration and protective performance for industrial and architectural projects. Precision weaving guarantees uniform square hole shape and consistent aperture size. This mesh can be cut bent and fabricated into custom filter discs or protective panels. Stainless galvanized or aluminum materials can be selected according to different corrosive environments. Installation manuals for metal screen cladding are published by Sheet Metal and Air Conditioning Contractors' National Association.
Material mechanical test results can be reviewed in Journal of Materials Engineering and Performance. Building specifiers can get screen facade design advice from Construction Specifier Magazine. Structural metal panel research papers are published by International Journal of Steel Structures. Metal fabrication engineering resources are hosted by Steel Construction Institute.
Plain weave wire mesh plain woven wire cloth stainless steel plain weave mesh galvanized plain weave wire mesh aluminum plain woven screen filter sieve mesh square opening woven wire mesh 304 plain weave wire mesh 316L plain woven mesh industrial sieving wire mesh equipment guard woven screen architectural ventilation plain weave mesh powder grading mesh liquid filter woven cloth custom cut plain weave mesh plain weave mesh 1220mm width plain weave mesh roll 30m 4mesh stainless mesh 6mesh woven screen 8mesh plain weave cloth 10mesh sieve mesh 20mesh filter wire mesh 30mesh stainless plain weave 40mesh woven metal screen 60mesh sieving mesh 80mesh filter cloth 100mesh stainless wire mesh 120mesh fine filter screen 200mesh ultra-fine woven mesh square hole metal screen ISO certified plain weave wire mesh ASTM woven wire cloth custom woven wire mesh manufacturer wire mesh supplier China sieving woven wire mesh industrial protective metal screen
Looking for plain weave wire mesh with custom mesh count wire diameter or cut sheet size Send your sieving filtration requirements our engineering team will provide free technical assessment and competitive quotation for your plain woven wire cloth project
